Digital Coating Thickness Gauge

PosiTector® 6000

Coating Thickness Gauges for ALL Metal Substrates
The rugged, fully electronic PosiTector 6000 Paint Thickness Gauge uses magnetic and eddy current principles to measure paint thickness on ferrous and non-ferrous metals quickly and accurately.

Modele

  • Digital Coating Thickness Gauge - FN1

    Standard model, combined ferrous and non-ferrous, integrated probe, 0 - 60 mils, 0 - 1500 μm

  • Digital Coating Thickness Gauge - FNS1

    Standard Model, Combined Ferrous and Non-Ferrous, Remote Probe, 0 - 60 mils, 0 - 1500 μm

  • Digital Coating Thickness Gauge - FN3

    Advanced model, combined ferrous and non-ferrous, integrated probe, 0 - 60 mils, 0 - 1500 μm

  • Digital Coating Thickness Gauge - FNS3

    Advanced Model, Combined Ferrous and Non-Ferrous, Remote Probe, 0 - 60 mils, 0 - 1500 μm

Description

  • Ready to measure—no calibration adjustments required for most applications
  • Large, impact-resistant 2.8-inch color touchscreen with redesigned keypad for quick menu navigation
  • Weather, dust, and water resistant—IP65-rated enclosure
  • Wear-resistant ruby ​​probe tip for long-term calibration
  • PosiTector interchangeable platform—attach any PosiTector probe to a single gauge body
  • USB, WiFi, and Bluetooth connectivity to PosiSoft PC, Mac, and smartphone software
  • NIST or PTB traceable calibration certificate included (long form)
  • Meets ISO 2178/2360/2808, ISO 19840, ASTM B244/B499/D1186/D1400/D7091/E376/G12, BS3900-C5, SSPC-PA2, US Navy NAVSEA PPI 63101-000, US Navy NAVSEA 009-32, AS 2331.1.4, AS3894.3-B and others

Simple

  • Fast measuring speed: over 60 readings per minute. Enhanced FAST Mode: Over 90 readings per minute for quick inspection.
  • Ready to measure—no adjustments required for most applications
  • Large, impact-resistant 2.8-inch color touchscreen with redesigned keypad for quick menu navigation
  • On-gauge help explains menu items with the push of a button
  • Flashing display—ideal for noisy environments
  • RESET function instantly restores factory settings

Durable

  • Weatherproof, dustproof, and waterproof—IP65-rated housing
  • Ergonomic design with durable rubberized grip
  • Wear-resistant probe tip
  • Shock-absorbing rubber protective case for increased impact resistance
  • Two-year warranty on gauge body AND probe

Accurate

  • NIST or PTB traceable calibration certificate included
  • Built-in temperature compensation ensures measurement accuracy
  • Hi-RES mode increases displayed resolution for precision applications
  • Complies with national and international standards including ISO and ASTM

Versatile

  • PosiTector body accepts all PosiTector 6000, 200, RTR, SPG, DPM, IRT, SST, UTG, SHD, BHI and GLS probes easily converting from a coating thickness gauge to a surface profile gauge, dew point meter, soluble salt tester, wall thickness gauge ultrasonic tester, hardness tester or gloss meter
  • Multiple calibration setting options including 1 point, 2 points and ISO 19840 correction factors
  • Selectable display languages
  • Auto-rotating display with toggle lock
  • Extended cables available (up to 75 m/250 ft) for underwater or remote measurements
  • Mils/Microns/mm switchable

Powerful

  • Statistics mode continuously displays/updates average, standard deviation, min/max, and number of readings during measurement
  • Screenshot: Record 100 screen images for record keeping and review
  • HiLo alarm audibly and visibly alerts when measurements exceed user-specified limits
  • Instant power-on feature quickly powers up the gauge if it has been recently powered off
  • Over 20 hours of continuous operation on 3 AAA batteries
  • USB port for quick and easy connection to a PC and continuous power. USB cable included.
  • Every recorded measurement is time-stamped
  • Web-based software updates keep your gauge up to date
  • Software solutions for data visualization, analysis, and reporting





See probe compatibility chart for more information.

Standard Models

Includes ALL features described above plus...

  • NEW 1,000 Reading Storage per Probe: Recorded readings can be viewed or downloaded

Advanced Models

Includes ALL features described above plus...

  • 250,000 reading storage in up to 1,000 batches and subbatches
  • Live graphing of measurement data
  • Prompted Batch Mode: Create predefined batches with on-screen text and graphical prompts for each reading
  • 3 Scan Modes: Increase measurement speed to over 180 readings per minute
    Normal: Take continuous readings without lifting the probe
    Statistics: Take continuous readings and record the average, standard deviation, min/max thickness and number of readings during scanning
    Limited Count Average: Take continuous readings up to a user-specified count. Gauge displays and records average readings.
  • Touchscreen keypad for quickly renaming batches, adding notes and more
  • Multiple saved calibration settings for measuring on a variety of substrate conditions
  • Calibration Setting Report feature documents calibration settings in PosiSoft software reports
  • SSPC-PA 2, ISO 19840 and IMO PSPC 90/10 modes help users comply with standards by requesting min/max specifications, displaying required readings and automatically calculating statistics with a pass/fail result
  • WiFi technology wirelessly syncs with PosiSoft.net and downloads software updates
  • Bluetooth 4.0 technology for data transfer to a mobile device running the PosiTector app or an optional portable printer. BLE API available for integration into third-party software
  • Integration with third-party software, drones, ROVs, PLCs, and robotic devices using multiple industry-standard communication protocols
  • Connect a barcode scanner or Bluetooth keyboard to instantly annotate readings and batches

Selection Guides

Additional information

Modèle

FN1, FN3, FNS1, FNS3
